| Width – A | 8' 5" (2.6 m) |
| $0.00 |
| Overall width (inlcuding loading arm) | 9' 1" (2.8 m) |
| $0.00 |
| Height – C | 7' 5" (2.3 m) |
| $0.00 |
| Overall height (inlcuding loading arm) | 12' 6" (3.8 m) |
| $0.00 |
| Bed height | 3' 9" (1.2 m) |
| $0.00 |
| Overall length – E | 24' 9" (7.6 m) |
| $0.00 |
| Overall weight | 3010 kg (6636 lb) |
| $0.00 |
| Weight on tow bar | 680 kg (1499 lb) |
| $0.00 |
| 0 | 0 |
| $0.00 |
| Round bale diameter | Up to 5' (1.5 m) |
| $0.00 |
| Square bale | n/a |
| $0.00 |
| Bale type | Baleage & dry hay |
| $0.00 |
| 0 | 0 |
| $0.00 |
| Loading capacity on axle (inc bale carrier) | 12 247 kg (27 000 lb) |
| $0.00 |
| Unloading angle | 40° |
| $0.00 |
| Hydraulic push ramp system | Standard |
| $0.00 |
| Full charge indicator | Standard |
| $0.00 |
| Double plate hitch | Standard |
| $0.00 |
| Road lights | Standard |
| $0.00 |
| Tandem axle | Standard |
| $0.00 |
| Safety chain | Standard |
| $0.00 |
| Self-loading arm design | Tubular round |
| $0.00 |
| Able to load a second row of bales | n/a |
| $0.00 |
| Tires | 400/60-22.5 |
| $0.00 |
| Tractor Minimum Hydraulic Flow | 10 Gal/min (37 litres/min) |
| $0.00 |
| Tractor Minimum Hydraulic Pressure | 2200 psi |
| $0.00 |
| Tractor Minimum HP requiements | 100 HP |
| $0.00 |
| Tractor Remote outlets required | 3 |
| $0.00 |
| PTO Speed / PTO shaft | n/a |
| $0.00 |
| Controls | 0 |
| $0.00 |
| 0 | 0 |
| $0.00 |
| Round bale 4' × 4' diameter (1.2 m × 1.2 m) | 10 |
| $0.00 |
| Round bale 4' × 5' diameter ( 1.2 m × 1.5 m) | 10 |
| $0.00 |
| Round bale 6' diameter (1.2 m × 1.6 m) | 10 |
| $0.00 |
| Round bale 5' × 5" diameter ( 1.5 m × 1.5 m) | 8 |
| $0.00 |
| Round bale 5' × 6' diameter (1.5 m × 1.6 m) | 8 |
| $0.00 |
| Square bale 3' × 3' × 8' lng (90cm× 90cm × 2.4m) | n/a |
| $0.00 |
| Square bale 4' × 3' × 8' lng (1.2m× 90cm × 2.4 m) | n/a |
| $0.00 |
| Square bale 4' × 4' × 8' lng (1.2m× 1.2m × 2.4 m) | n/a |
| $0.00 |
| | "1135 kg |
| $0.00 |
| | "10 490 kg |
| $0.00 |
| | "10 490 kg |
| $0.00 |
| | "10 490 kg |
| $0.00 |
| On a distance of 0.62 mile 3' × 4' | 55 |
| $0.00 |
| On a distance of 1.24 mile 3' × 4' | 36 |
| $0.00 |
| On a distance of 1.86 mile 3' × 4' | 26 |
| $0.00 |
| On a distance of 2.48 miles 3' × 4' | 21 |
| $0.00 |
| On a distance of 3.10 miles 3' × 4' | 17 |
| $0.00 |
| Width – A | 8' 5" (2.6 m) |
| $0.00 |
| Overall width (inlcuding loading arm) | 9' 1" (2.8 m) |
| $0.00 |
| Height – C | 7' 5" (2.3 m) |
| $0.00 |
| Overall height (inlcuding loading arm) | 12' 6" (3.8 m) |
| $0.00 |
| Bed height | 3' 9" (1.2 m) |
| $0.00 |
| Overall length – E | 24' 9" (7.6 m) |
| $0.00 |
| Overall weight | 3010 kg (6636 lb) |
| $0.00 |
| Weight on tow bar | 680 kg (1499 lb) |
| $0.00 |
| Round bale diameter | Up to 5' (1.5 m) |
| $0.00 |
| Square bale | n/a |
| $0.00 |
| Bale type | Baleage & dry hay |
| $0.00 |
| Unloading angle | 40° |
| $0.00 |
| Hydraulic push ramp system | Standard |
| $0.00 |
| Full charge indicator | Standard |
| $0.00 |
| Double plate hitch | Standard |
| $0.00 |
| Road lights | Standard |
| $0.00 |
| Tandem axle | Standard |
| $0.00 |
| Safety chain | Standard |
| $0.00 |
| Self-loading arm design | Tubular round |
| $0.00 |
| Able to load a second row of bales | n/a |
| $0.00 |
| Tires | 400/60-22.5 |
| $0.00 |
| Tractor Minimum Hydraulic Flow | 10 Gal/min (37 litres/min) |
| $0.00 |
| Tractor Minimum Hydraulic Pressure | 2200 psi |
| $0.00 |
| Tractor Minimum HP requiements | 100 HP |
| $0.00 |
| Tractor Remote outlets required | 3 |
| $0.00 |
| Round bale 4' × 4' diameter (1.2 m × 1.2 m) | 10 |
| $0.00 |
| Round bale 4' × 5' diameter ( 1.2 m × 1.5 m) | 10 |
| $0.00 |
| Round bale 6' diameter (1.2 m × 1.6 m) | 10 |
| $0.00 |
| Round bale 5' × 5" diameter ( 1.5 m × 1.5 m) | 8 |
| $0.00 |
| Round bale 5' × 6' diameter (1.5 m × 1.6 m) | 8 |
| $0.00 |
| Maximum loading capacity (lb) | 1135 kg (2500 lb) |
| $0.00 |
| Maximum utility load capacity (25km/h) | 10 490 kg (23 130 lb) |
| $0.00 |
| Maximum utility load capacity (40km/h) | 10 490 kg (23 130 lb) |
| $0.00 |
| Maximum utility load capacity (50km/h) | 10 490 kg (23 130 lb) |
| $0.00 |
| On a distance of 0.62 mile 3' × 4' | 55 |
| $0.00 |
| On a distance of 1.24 mile 3' × 4' | 36 |
| $0.00 |
| On a distance of 1.86 mile 3' × 4' | 26 |
| $0.00 |
| On a distance of 2.48 miles 3' × 4' | 21 |
| $0.00 |
| On a distance of 3.10 miles 3' × 4' | 17 |
| $0.00 |
| Loading capacity on axle (including bale carrier weight) | 12 247 kg (27 000 lb) |
| $0.00 |
