Attachment Size:
|
Round bale 4 ft x 4 ft diameter 14 none wrapped bales
|
| Round bale diameter | Up to 6 ft (1,8 m) | | Square bale | n/a | | Bale type | Baleage/dry hay/straw |
| Tandem axle | Standard | | Tandem axle with brakes | Optional | | Self-Steering axle with brakes | Optional | | Safety chain | Standard | | Self-loading arm design | Tubular round | | Able to load a second row of bales | N/A | | Tires | 550/45-22,5 | | Caméra (de recul) | Optional | | Tractor minimum hydraulic flow | 2500 psi (172 bar) | | HP requirements | 115 HP | | Double hydraulic connections required | 3 | | PTO Speed/ PTO shaft | N/A | | Controls | Tractor’s hydraulic circuit |
| Width – A | 8 ft 4 in (2,55 m) | | Overall width (inlcuding loading arm) | 8 ft 4 in (2,55 m) | | Height – B | 7 ft 10 in (2,39 m) | | Overall height (inlcuding loading arm) | 11 pi 11 po (3,64 m) | | Bed height - E | 4 pi 9 po (1,44 m) | | Overall length – D | 38 pi 5 po (11,76 m) | | Overall weight | 12790 lb (5800 kg) | | Empty Weight on tow bar*** | 2855 lb (1295 kg) |
| Round bale 4 ft x 4 ftdiameter (1,2 m x 1,2 m) | 14 | | Round bale 4 ft x 5 ft diameter (1,2 m x 1,5 m) | 14 | | Round bale 4 ft x 6 ft diameter (1,2 m x 1,8 m) | 14 | | Round bale 5 ft x 5 ft diameter (1,5 m x 1,5 m) | 12 | | Round bale 5 ft x 6 ft diameter (1,5 m x 1,8 m) | 12 | | Square bale 3 ft x 3 ft x 8 ft long (90 cm x 90 cm x 2,4 m) | n/a | | Square bale 4 ft x 3 ft x 8 ft long (1,2 m x 90 cm x 2,4 m) | n/a | | Square bale 4 ft x 4 ft x 8 ft long (1,2 m x 1,2 m x 2,4 m) | n/a | | Loading arm lifting capacity | 2500 lb (1135 kg) |
|
