Machine Size:
|
15,400LBS-19,800LBS (24GPM-32GPM)
|
|
Arrowhead Rockdrill’s R Range hydraulic hammers bring a new industry leading tie-rodless hammer to the market. Based around a unique design the R Range hammers eliminate the need for tie rods in the hammer assembly increasing the robustness of the hammer while simplifying its construction. The R Range hammers are a compact and powerful design suitable for a wide variety of applications all with the effective price and industry leading support our customers deserve. Features- Tie-rodless hammer design
- Narrow round box provides superior access to surfaces in confined spaces such as trenching work
- Vibration and sound supressed at standard
- Full servicing using no specialist tools
- Powerful gas fired operation using less oil at lower working pressures
- Excavator friendly
| Specifications | | R90 | R100 | R120 | R140 | R155 | | Required Flow Rate | us g/m
L/m | 24 - 32
90 - 120 | 26 - 37
100 - 140 | 24 - 40
90 - 150 | 40 - 53
150 - 200 | 45 - 58
170 - 220 | | Operating Pressure | psi
bar | 1885
130 | 1885
130 | 1885
130 | 1885
130 | 2175
150 | | Blow Rate | per minute | 600 - 1200 | 800 - 1400 | 400 - 700 | 400 - 700 | 380 - 500 | | Sound Rating | dB | 123 | 123 | 125 | 127 | 129 | | Tool Diameter | inches
mm | 3.5
90 | 3.9
100 | 4.7
120 | 5.5
140 | 6
155 | | Working Weight | lbs
kg | 1146
520 | 1455
660 | 2667
1210 | 3483
1580 | 5000
2250 | | Carrier Weight | lbs
tonnes | 17640 - 28660
8 - 13 | 28660 - 35275
13 - 16 | 35275 - 46300
16 - 21 | 44095 - 63935
20 - 29 | 56000 - 86000
25 - 39
|
|
