Machine Size:
|
14,000LBS-36,000LBS 20GPM-35GPM
|
|
Excavator mounted Stump Grinder - GXM750
The GXM750 excavator stump grinder is designed with high performance in mind for 7 to 18 ton excavators equipped with 8 to 40 gallons per minute of flow. It Features 20 green carbide teeth packed in groups of 5. The Wearsharp® Teeth can be rotated for a fresh edge up to three times, letting you grind stumps 3 times longer. Heavy tooth population makes finer mulch and allows much smoother operation, while the blast shield with double row chain curtain ensures debris stays put. The 24" rotor is powered by a bent axis a piston motor, which provides ample stump grinding in virtually any location your excavator can reach. The GXM750 Baumalight stump grinder is offered with three motor options to best match your flow; be sure to check out the Stump Cutting Times charts below to see how fast you can grind stumps with the flow of your excavator. | Model No. | S14 | S18 | GXM350 | GXM550 | GXM750 |
|---|
| Baumalight Connection Code | A04 | A04 | A02 | A02 | A02 | | Recommended Carrier Size | 1-2 ton | 1.5-4 ton | 1.5-4.5 ton | 3.5-8 ton | 7-18 ton | | Motor Type | Gerotor | Gerotor | High efficiency bent axis piston | High efficiency bent axis piston | High efficiency bent axis piston | | Hydraulic GPM | Check Motor Options | Check Motor Options | Check Motor Options | Check Motor Options | Check Motor Options | | Rotor Size | 18" | 24" | 19" | 24" | 24" | | Number of Teeth | 12 | 34 | 12 | 12 | 12 | | Tooth Part number | H3000 | S1000 | H3000 | H3000 | H3000 | | Tooth Construction | High speed | Planer | High speed | High speed | High speed | | Cutting Wheel Speed | Depends on GPM | Depends on GPM | Depends on GPM | Depends on GPM | Depends on GPM | | Cutting Height - Above Ground | No limit | No limit | No limit | No limit | No limit | | Cutting Depth - Below Ground | 6" | 10" | 16" | 24" | 24" | | Maximum Cutting Depth - Per Pass | 2" | 5" | 3/4" | 1" | 1" | | Maximum Horizontal Cut | 12" | 22" | 12" | 22" | 22" | | Over Torque Protection | Relieve valve | Relieve valve | Relieve valve | Relieve valve | Relieve valve | | Hitch | 1" pivot pins | 1" pivot pins | Bolt on | Bolt on | Bolt on | | No. of Remotes Required - Hydraulic | 1 | 1 | 1 | 1 | 1 | | Requires 12 Volt DC | No | No | No | No | No | | Unit Weight (Shipping) Lbs. | 394 | 642 | 650 | 822 | 1300 |
|
